FJG1002 Crawler Tractor with 100 hp power, 450 mm tracks, 12F/12R, 260 L fuel tank. Built for deep-mud paddy fields, with high clearance.
Differential steering allows pivot turns at the headland, while automatic implement lift on reverse shortens the turning cycle. The tracked chassis keeps working through deep mud and soft paddy soil where wheeled tractors bog down, with strong anti-sinking capability.
Advantages
• High clearance for soft, ridged ground
• 12F/12R transmission for fine speed matching
• 720/1000 rpm two PTO speeds match a wider range of implements for paddy and dryland work.
Specifications
| Item | Unit | Value |
|---|---|---|
| Overall Dimensions (L × W × H) | mm | 4280 × 1910 × 2690 |
| Min. Operating Weight | kg | 3320 |
| Min. Ground Clearance | mm | 560 |
| Track (Width × Pitch × Links) | mm | 450 × 90 × 58 |
| Track Gauge | mm | 1300 |
| Track Contact Length | mm | 1440 |
| Steering Type | / | Differential Steering |
| Gears (Forward/Reverse) | / | 12/12 |
| Max. Travel Speed | km/h | 16 |
| PTO Speed | r/min | 720/1000 |
| Engine Manufacturer | / | YTO (Luoyang) Diesel Engine Co., Ltd. |
| Engine Model | / | YTN3115-44 (China Stage IV) |
| Rated Power | hp | 100 |
| Fuel Tank Capacity | L | 260 |
